AMPD Bros Ace-X PRO S4 Dual Suspension Fat Tyre Electric Bike
-
ColorPlease choose your colour and/or size.?In Stock?
Couldn't load pickup availability
Shipping & Pickup Information
Shipping & Pickup Information
Australia wide postage available or local pick-up, choose at checkout.
Fast shipping Australia wide on all orders. We only use trusted couriers like Australia Post & TNT to ensure your item(s) arrive quick & safely.
View our shipping T&C's here.
AMPD Bros Ace-X PRO S4 Dual Suspension Fat Tyre Electric Bike
AMPD Bros Ace-X PRO S4 Dual Suspension Fat Tyre Electric Bike
Shipping options (choose option at checkout once added to cart):
1. Ship to home ($150)
Get your new bike delivered in a box. ATTENTION: Whilst minimal assembly is required, basic mechanical skills and proper tools are a must. If your order includes additional items, they may arrive separately from the bike. We highly recommend taking your bike to a local bicycle mechanic if you are in any doubt when attempting assembly. If you decide to take your bike to a 3rd party for assembly or to check over of your own work, additional fees will apply and these are at your own expense. If any damage is evident to the box when it arrives please take photos and contact us prior to attempting assembly.
2. Drift Bikes Fully Assembled Delivery ($375 - within 50km of store. This cost is made up of $150 for Delivery and $225 for Assembly.)
Get your new bike hand-delivered to your shipping address already professionally assembled by Drift Bikes mechanics. Our team will contact you when your bike is built and ready for delivery. If your order includes additional items, they will be delivered with your bike.
3. Pickup in-store (*FREE)
Pick up your new bike in a box. ATTENTION: Whilst minimal assembly is required, basic mechanical skills and proper tools are a must.
*We highly recommend paying our workshop $225 to professionally assemble your Ampd Bros bike. If selecting pick up in-store we will contact you to check if you would like to pick up your boxed bike or have it professionally assembled. You can pay for assembly upon pickup. If choosing to take your bike in a box for self-assembly you assume any expenses related to your own mechanical work to be at your own expense.
Professional assembly includes:
Full assembly of the bike along with recycling the box (we pay for it to be recycled).
Assembly includes: Checking hanger alignment, pre stressing cables, training brake pistons, test derailleur limits, check ALL bolts along with test riding the bike to bed brakes in along with re-calibration and finally have the bike checked by a second mechanic. The build also insures we cover all warranty issues in the first 12 months as well as guaranteeing our build for 90 days and offering a free valued at $140. We feel we offer exceptional value for the $225 Ampd Bros build.
Please note, boxed bikes are stored at our warehouse location and may take up to 2 days to be transferred to the retail store.
Professionally assembled bikes can take up to 10 working days in peak season.
ATT: The 250W (500W for NSW) motor is road legal and doesn't require a licence or registration. The 750W and 1000W motor is for off-road (private property) use only.
About this bike:
Hold on tight, because the All NEW 2025, Series 4 ACE-X PRO Dual Suspension Electric Bike is here to blow your mind! Inspired by our legendary ACE Model Range, the ACE-X PRO just took a quantum leap forward!
Say goodbye to the ordinary, because the ACE-X PRO leaves its predecessor, the ACE-X in the dust. We've supercharged it with a mind-boggling 1,000W Rear Hub Bafang Motor that delivers mind-blowing ride performance like never before seen on an Ace Bike! And for those seeking next-level comfort, we've added our signature DNM Rear Suspension for an ultra-smooth ride.
Designed in conjunction with our in-house family team and continuously sought after since its debut in 2019, the ACE Bike continues to create waves nationwide.
Loaded with premium features and celebrated year after year as Australia's favourite fat tyre bike the ACE Pro range boasts a vibrant colour options and a cutting-edge battery system with our Latest GEN3 Aluminium Battery which encompasses 21700 cells that are 30% larger than our competitors, paired with our Smart BMS for optimal performance and safety.
What's New for Series 4?
- All New 52V 25AH Battery with Premium 21700 Samsung Cells
- Improved 4 Piston Tektro Hydraulic Brakes with 203mm Rotors
- Enhanced Adjustable Front Fork with CNC Bar Clamps
- 4 Premium New Metallic Paint Finishes, including the showstopper "Bronze Eclipse", Gloss Midnight Black, Gloss Jungle Green and Matte Titanium.
- Patented Rear Suspension Design Enabling 100mm of Seat Height Adjustment
- Plush Quilted Seat and VEE Tire Huntsman Puncture Resistant Tyres
Step up to the ACE-X PRO, our iconic high cross bar "X" frame model. Equipped with an adjustable coffee cup and bottle holder, a spacious seat for two, and a massive Removable Samsung Battery with a 100km Range, this beast will take you on unimaginable adventures. Paired with Bafang's High Torque 95Nm Motor, no terrain can hold you back – beaches, hills, dirt tracks, grass, or pavement, you name it!
Feel the surge of adrenaline as the insane levels of torque propel you forward, conquering every obstacle in your path. Pedal Assist is standard, but with our Off Road Throttle Kit, you can cruise effortlessly with minimal effort. Gear shifts are lightning-fast and precise, thanks to the 7-speed Shimano Rapid Fire trigger shifter and Altus transmission.
Speed & Range
- Range 100km* (Single Motor Only)
- Top Speed 25km/h (or Unlock up to 55km/h for Private Property Use)
Battery
- Standard 52V / 1,300Wh, 25AH
- Samsung Premium 21700 Lithium cells
- Battery is removable and can be charged in bike or separately.
Motor
- Bafang Hub Limited to 250W (Unlocked 1,000W Nominal)
- Torque 95N.m (Each Motor)
- Peak Output 1,600W+ (Each Motor)
- ACE Pro Single Rear Wheel Drive
- ACE Demon Dual AWD Front & Rear Motors
Ride Modes
- Mode 1 Pedal Assist mode: Adjustable pedal assist performance settings from 1-5 or can also be changed to 1-3 or 1-9
- Mode 2 Walk mode: Idles bike up to 6km/h to assist with moving bike by holding the "-" button on the keypad
- Mode 3 Throttle mode: Available when Optioned with the Off Road Throttle Kit
Features
- Hill Ability Up to 30º Degree / 60% Incline PAS
- Seat Custom Large Quilted Plush Dual Seat for 2 Riders
- Warranty 2 Years (1 Year on Batteries)
- Ace Pro Headlight Ampd Bros Signature 800lm LED Light with DRL
- Demon Headlight Upgraded PRO Front LED 1,700lm Headlight with DRL
- Lights Rear LED Brake Light inbuilt to battery pack
- Grips Velo Wide Comfort
- Bell Yes
Brakes
- Standard Tektro 4 Piston Hydraulic Disc
- Discs 203mm
- E-Brakes Yes Motor Safety Cut Off
Display
- Colour LCD Multi-Function with USB, ODO, Trip, Battery Level, Speed etc
Controller
- Ampd Brothers Custom - Best-in-class power density and state-of-the-art motor control algorithms.
Drivetrain
- Transmission Shimano 7 Speed with Rapid Fire Micro Shifter
- Derailleur Shimano Altus
- Pedals Wellgo Alloy - Black
- Chain KMC Z Series High Performance
Construction
- Frame Aluminium - "X" Step Over Bar Design
- Handlebars Aluminium Motorcycle Inspired with Adjustable Height
- Fenders Matte Black Aluminium
Suspension
- Standard Front Independent & Rear Adjustable DNM
Wheels & Tyres
- 20x4.0" Vee Tire Huntsman Puncture Resistant All Terrain Tyres
Charging
- 8.5hrs for 25Ah Batteries with Standard 3A Included Charger
- Optional 5A Fast Charger Available
Dimensions
- Overall Length 1,800 mm
- Handlebar Height 1,140 - 1,190 mm
- Handlebar Width 660 mm
- Seat Height 880mm (Adjustable between 850-950mm)
- Seat Length 600 mm
- Ground Clearance 270 mm
- Wheel Base 1,160 mm
- Rider Height Ideal for Riders up to 200cm Tall
Weights
- N.W of 25Ah Battery 6.25 kg
- N.W of ACE Pro + Battery 44.4 kg
- N.W of ACE Demon + Battery 49 kg
- Max Loading 180 kg
Inclusions
- In Box Bike, Battery, 3A AUS Charger, Front Headlight, Basic Tool Kit, Manual, Pedals, Fenders, Seat & Kick Stand.
*Range Achievable may vary based on loading, motor use, throttle/pas, terrain, weather conditions and many other factors.
