Soma Juice Gates 29ER Trail XC/Hard Tail Frame (Battleship Grey - Medium)
Shipping options (choose option at checkout once added to cart):
1. Drift Bikes Delivery ($150 - within 50km of store)
Get your new bike hand-delivered to your shipping address by a Drift Bikes expert, professionally built and set up just for you. Your bike will be professionally assembled by Drift Bikes mechanics and hand-delivered to your home address. Our team will contact you when your bike is built and ready for delivery. If your order includes additional items, they will be delivered with your bike.
2. Pickup in-store (free)
Pick your new bike at Drift Bikes Kotara. All bikes are professionally built and set up just for you. Please note, some bikes are still in boxes and can take up to 10 working days to assemble.
About this bike:
The Juice is our trail/XC hardtail frame for 29" wheels. This updated version features tough Broski Sliding Dropouts that allow you to go single-speed or geared or even run hub gears and slightly more modern geometry. Also new is internal seat tube dropper post routing. A modified chainstay allows fitting even some double cranks with “plus size” 2.8" wide tires without needing to invest in Boost 148 parts. We even offer a belt-drive ready version if you want to run a Gates Carbon Drive. (*Belt-drive version works with regular chains as well)
– Tange Prestige heat-treated butted CrMo steel; butted CrMo rear end
– Geometry is optimized for 100mm travel 29" forks and will handle 120mm forks great, too (Ideal rigid fork length: 485mm)
– Disc brakes only (ISO tabs)
– Standard or Belt-Drive compatible versions available (split for installing belt is on the seatstay.)
– IRD Broski Sliding Dropouts allows geared and single-speed builds with easy wheel removal
– In 2021 these come ready for 142 x 12mm Thru-Axle hubs. (Can be converted to 135mm spacing for traditional QR hubs with IRD aftermarket inserts)
– S-bend seatstays and chainstays
– Rear rack and fender eyelets
– CNC-machined 44mm headtube: Will take 1-1/8" steerers with a ZeroStack 44 headset or tapered steerers with a ZS44 upper assembly and external cup (EC44) lower assembly
– 31.6mm post size/34.9mm frt. der. size/34.9mm seat collar/73mm bottom bracket (English threads); 400mm+ post recommended
– Recommended tire size: 29" x 2.4" (or 27.5 x 2.8”)
